2091.94. Flanged guide bush ECO-LINE, bronzeplated, ISO 9448-4
Material:
Steel, d3 induction hardened Execution:
Bronze coated internal bore.
Outside diameter fine-ground.Note:
The guide bush is fixed by means of 3 srews up to ø 16: with screws to DIN 6912, from ø 19: with screws to DIN EN ISO 4762.
The screws are not contained in the scope of delivery.
↗ Notes on sliding type guides at the beginning of chapter D.
↗ Matching guide combinations, see selection matrix at the beginning of chapter D.
↗ Assembly guide lines / Dimensional requirements and tolerances at the end of chapter D.
Steel, d3 induction hardened Execution:
Bronze coated internal bore.
Outside diameter fine-ground.Note:
The guide bush is fixed by means of 3 srews up to ø 16: with screws to DIN 6912, from ø 19: with screws to DIN EN ISO 4762.
The screws are not contained in the scope of delivery.
↗ Notes on sliding type guides at the beginning of chapter D.
↗ Matching guide combinations, see selection matrix at the beginning of chapter D.
↗ Assembly guide lines / Dimensional requirements and tolerances at the end of chapter D.
Log in to view price, availability, and order the product.
Products
Showing 1-10 of 12 items
| SKU | Guide diameter | |
|---|---|---|
| 2091.94.015 | 15 mm | |
| 2091.94.016 | 16 mm | |
| 2091.94.019 | 19 mm | |
| 2091.94.020 | 20 mm | |
| 2091.94.024 | 24 mm | |
| 2091.94.025 | 25 mm | |
| 2091.94.030 | 30 mm | |
| 2091.94.032 | 32 mm | |
| 2091.94.038 | 38 mm | |
| 2091.94.040 | 40 mm | |
| 2091.94.048 | 48 mm | |
| 2091.94.050 | 50 mm |
